140CPU67160

Description

argument
Clock frequency: 266 MHz
Memory capacity:
Internal RAM: 1024 kB and 512 kB are dedicated to data
Scalable file storage capacity: 8 MB via PCMCIA card
Expand program storage capacity: 7168 kB with PCMCIA card
I/O features: Dedicated I/O includes counters, accurate timestamps, high-speed interrupt outputs, and serial links
specification
Series: Modicon Quantum automation platform series
Type: Quantum Hot Standby CPU (HSBY), unity Hot Standby processor
Connection options:
A USB port
Two distributed as interfaces
Four remote AS interfaces
Six local Modbus Plus connections
Six local Profibus DP connections
A Modbus connector
Six local Ethernet TCP/IP connections
Optional modules: Ethernet, Modbus, Modbus Plus, Profibus, DP, and Sy/Max
Size and weight
Dimensions: The overall dimensions are approximately 90 x 100 x 81 mm
Weight: 0.3673 kg
trait
Multi-mode Ethernet connection: Supports multiple Ethernet connection modes
LCD: Covered by the lens cap, standard configuration is a 2-line 16-character LCD with variable backlight status and contrast
Automatic backlight processing: The keyboard driver will automatically turn on the backlight when it detects the key, and automatically turn it off after 5 minutes, and the backlight will remain on when an error is detected
Security function: The key switch has a memory protection function and has two positions (lock and unlock) to control access to the system menu and module parameters
Highly adaptable: With a range of optional modules, the processor is highly adaptable and flexible, able to meet different requirements and specifications
