140CPU67160

Description

trait
Display: LCD covered by the lens cap, standard configuration as a 2-line 16-character LCD with variable backlight status and contrast
Keyboard: Five keys map to hardware addresses, including two arrow keys, each with an LED. The automatic backlight processing function automatically turns on the backlight when a key is detected, turns it off automatically after 5 minutes, and the backlight is on if an error is detected
Connectivity options: Include one USB port, two distributed AS interfaces, four remote AS interfaces, six local Modbus Plus connections, six local Profibus DP connections, one Modbus connector, and six local Ethernet TCP/IP connections
Optional modules: Ethernet, Modbus, Modbus Plus, Profibus, DP, and Sy/Max provide a high degree of adaptability and flexibility through these modules
Security function: Equipped with key switch with memory protection function, you can switch between lock and unlock positions to control access to system menu and module parameters
Battery and reset button: Built-in battery and reset button to ensure the stable operation of the device and fault recovery

Parameters and specifications
Clock frequency: 266 MHz
Local rack: two
Dedicated I/O: Includes counters, accurate timestamps, high-speed interrupt outputs, and serial links
Internal RAM: 1024 kB and 512 kB are dedicated to data
File storage capacity: 8 MB scalable storage capacity via PCMCIA card
Program storage capacity: 7168 kB of expand able storage capacity with PCMCIA card
Size and weight
Product size: 166mm x 112mm x 36mm
Product weight: about 375g
It is also said to have a dimensions of 90 x 100 x 81mm and a weight of 0.3673kg.
​
