140CPU65860

Description

‌Specifications‌:

‌Product Type‌: Modicon Quantum Automation Platform, Unity Processor.
‌Clock Speed‌: 266 MHz.
‌Memory‌: Expandable up to 8 MB with PCMCIA card.
‌Internal RAM‌: 11264 kB.
‌Communication Ports‌: Includes RS 232Modbus, Modbus Plus, TCP/IP Ethernet, and USB ports.
‌I/O Capacity‌: Supports a large number of discrete and analog I/O points.
‌Operating Temperature Range‌: -20°C to +50°C.

‌Functions‌:

Acts as the central processing unit (CPU) for the Modicon Quantum automation platform.
Handles tasks such as scanning, I/O acquisition, processing interrupts, and communication.
Stores applications in battery-backed internal RAM.

‌Weight‌:

Approximately 1.467 kg as mentioned in one specification.
Another source mentions a weight of about 120g, but this might refer to a different part or a typo, so further confirmation is needed.

‌Dimensions‌:

170mm x 105mm x 32mm (as per one specification, which might refer to the product size rather than just the CPU).

‌Characteristics‌:

Features a high-performance processor.
Compatible with UnityPro software.
Equipped with an LCD display for diagnostics and maintenance.
Includes memory protection features to prevent unauthorized access or tampering.

‌Application Areas‌:

Primarily used in industrial automation systems, including process control and manufacturing environments.
Suitable for applications requiring high-speed processing and extensive I/O capabilities.
