Description
Parameters and specifications
Clock frequency: 166 Mhz.
File storage: Expandable 8 MB.
Programming space: 7168 kB or expandable.
RAM: 768 kB.
I/O points: 8,000 discrete inputs and outputs in a distributed network and 31,744 discrete inputs and outputs in a remote system.
Distributed I/O stations: 63.
Data rate: 10/100 Mbps.
Size and weight
Product size: 166mm x 112mm x 36mm.
Weight: 1.2kg (some say 1.3kg).
trait
Communication mode: Use RJ-45 connection for communication.
Network function: It integrates the diagnostic function of the network server and supports Ethernet TCP/IP, Modbus, Modbus Plus and USB connection types.
Expandability: Has expandable file storage and programming space.
Self-diagnosis function: It has self-diagnosis function and monitoring function to ensure the health state of the system.
Hot swap: All modules support hot swap, allowing online replacement of faulty modules.
Web Server functionality: Although its Web server functionality is for diagnostic purposes only, it can be configured through software.
