Description
2. Specifications
Product type: Processor module
Series: Unity Series, Modecon Quantum series
Installation mode: modular
Package size: may vary, but generally includes the module itself and its accessories
3. Size and weight
Product size: Based on the search results, there are two different size information. One is 115mm x 48mm x 150mm and the other is 166mm x 112mm x 36mm. This could be a size difference between versions or configurations.
Product weight: approx. 1.2kg (according to one size information) or 1.3kg (according to another size information)
Step 4: Characteristics
Self-diagnostic and monitoring functions: ensure the health of the system and ensure the safety of signals and controls
Hot swap: Faulty modules can be replaced online, and I/O modules can be added or removed online without system restart
Network function: Combining the standard function of PLC and the diagnostic capability of the network server, RJ-45 connection is supported for communication
Multiple connection types: Ethernet TCP/IP, Modbus, Modbus Plus, USB, etc
1. Parameters
Operating voltage: May be 3V (may vary depending on product version and configuration)
Output frequency: 4Hz
Processing speed: 5μs
Program capacity: 12K
Data capacity: 213
Data rate: 10/100 Mbps
Clock frequency: 166 Mhz
File storage: Expandable 8 MB
Programming capacity: 7168 kB or scalable
RAM: 768 kB
