Description
Parameters and specifications:
Data transfer rate: 10Mbps (megabits per second) baseband transmission.
Transmission medium: Unshielded twisted pair (UTP).
Maximum length of each twisted pair: usually 100m (when using high-quality five types of wire, the maximum length can reach 150m).
The number of hubs allowed to connect to a channel: 4, up to 5 segments of transmission media.
Topology: Star or bus shaped, but usually a star topology is used.
Access control mode: CSMA/CD (Carrier Sense multiple access/collision detection).
Frame length: Variable, maximum 1518 bytes.
Maximum transmission distance: Although the maximum length of each twisted pair is 100m, the maximum transmission distance of the entire network can reach 500m (through multiple HUB connections).
Workstations that can be connected per HUB: 96
Series:
10BASE-T is not a product family, but a standard for Ethernet technology. However, there are other Ethernet technology standards related to it, such as 100BASE-T (100Mbps data rate).
Features:
Easy installation: Using UTP twisted pair, installation and maintenance is relatively simple.
Price advantage: Compared with thick and thin cables, the price is cheaper.
Good compatibility: It is compatible with Ethernet technologies such as 10BASE-2 and 10BASE-5.
Flexibility: The establishment and expansion of the network is very flexible and convenient, and the increase or decrease of workstations can not interrupt the entire network work.
Fault isolation: The HUB automatically isolates faults. When a workstation fails, the network will not be affected.
Functions:
10BASE-T is an important standard of Ethernet technology, which provides a data transmission rate of 10Mbps for computer networks and is suitable for small and medium-sized local area networks. By using UTP twisted pair, 10BASE-T provides a low cost, high flexibility and good compatibility networking solution.
