Description
argument
Control signal: 5-24V compatible.
Spot diameter: <1.5mm.
Power supply voltage: 12… 24VDC.
Response time: >1ms.
Hysteresis range: 1… Fifteen percent.
Repeat error: ≤3%.
Load current: ≤200mA.
Residual voltage: ≤2.5VDC.
Current consumption: ≤45mA.
Withstand voltage: 1000V/AC 50/60Hz 60s.
Insulation impedance: ≥50MΩ(500VDC).
specification
Type: Input/output module, also known as control module, used in the fire alarm linkage system.
Brand: ABB.
Output mode: NPN NO+NC.
Switch composition: transmitter and receiver integrated.
Detection distance: 10±2mm.
trait
Input/output function: When there is a control requirement, it can output a signal, or provide a switching signal to make the controlled device act, and it can receive the feedback signal of the device to report to the host.
Versatility: Input/output modules on the market can provide a pair of passive normally open/normally closed contacts to control the controlled device. Some manufacturers’ modules can be set to active output through parameter setting.
Electrical protection: May have surge, short circuit, reverse polarity protection and other electrical protection functions.
Environmental adaptability: Adapt to a wide range of ambient temperature and humidity, such as the ambient temperature of -25℃… 55℃, the ambient humidity is 35-85%RH.
