– high performance safety system
– intended for use in critical areas such as oil and gas, electricity generation and chemical processing
– ensures reliable and efficient control of processes
– ensures safe and efficient operation
– input voltage: 120-240 vac, 50/60 hz
– output voltage: 24 v dc, 4-20 ma
– operating temperature: – 20 to 60 degrees
– storage temperature: -40 c to 85 c
– 16 digital inputs
– 16 digital outputs
– 2 impulse inputs
– 2 impulses
This module is designed to work with a wide range of industrial control systems and is compatible with different programming languages and software platforms.
Triconex 3503e touch screen is designed to provide real-time monitoring and control of critical processes in industrial environments. It has a high-resolution display that provides clear and detailed information on the status of the system, alarms and other important parameters. The touch screen interface is intuitive and easy to use, facilitating navigation and control.
– display size: 10.4 inches
– display resolution: 800 x 600 pixels
Processor: Intel atom 1.6 GHZ
– memory: 2 gb ddr3
– storage: 32 gb SSD
Triconex 3721 provides 32 digital data entry channels, each capable of receiving signals from different sources. The module is designed to operate in harsh conditions with a wide range of operating temperatures and resistance to impact, vibration and electromagnetic interference.
– number of channels: 32
– input voltage range: 10-60 v dc
– input current: 5 ma @ 10 v dc, 30 ma @ 60 v dc
– input resistance: 2.5 CMS typical
– operating temperature: -40 c to +70 c
Input Type: Depending on the specific model, it can be configured as an analog input module, digital input module, or power module.
Channels: The analog input module variant offers multiple analog input channels for receiving voltage or current signals.
Resolution and Accuracy: High resolution and accuracy for precise signal measurement and acquisition.
Input Signal Range: Configurable for different types of analog signals, such as voltage or current, with corresponding signal ranges.
Communication: Supports communication and data exchange with other control devices or systems.
Supported Signals: The module supports 16 digital input signals and 16 digital output signals, enabling it to interface with a wide range of devices and systems
Programmability: It offers programmable working modes and logic, providing flexibility in configuring and adapting to different application requirements
Fault Diagnosis and Self-Test: Built-in fault diagnosis and self-test functions ensure reliable operation and easy troubleshooting
Communication Protocol: Supports the Modbus communication protocol, facilitating data exchange with other devices and systems
Operating Voltage Range: Designed to operate within a voltage range of 24VDC to 48VDC, making it suitable for various industrial applications
Input Voltage Range: 10.5-30V AC (RMS)1
Output Voltage Range: 0-10V AC (RMS)1
Output Current: Up to 24A1
Frequency: Up to 2500Hz1
Accuracy: ±1%1
Dimensions: Not specifically provided, but the power module variant has dimensions of 150mm x 100mm x 50mm2
Weight: The power module variant weighs 500g
Input voltage: 24VDC nominal value.
Operating temperature: -40℃ to 70℃.
Power consumption: 10W.
Number of channels: 16 channels
Analog input range: 4-20mA.
For the 3721 digital input card, its external dimension is 100mm×120mm×50mm, and the weight is 200g.
For the 3721 output module, the dimensions are 176 x 117 x 43 mm and the weight is 0.88 kg.
Processor: 32-bit processor.
Memory: 512MB of RAM and 1GB of flash memory.
Input/Output: 48 digital inputs, 48 digital outputs, 16 analog inputs, and 16 analog outputs.
Working Voltage: 24V DC.
Operating Temperature: -20℃ to 60℃.
Size: 483mm x 178mm x 127mm.
Weight: Approximately 5kg.
