Parameters:
–Input/Output Type: Typically a processor interface or communication module, designed to interface with other PLC modules or external devices12.
–Voltage: Supports a range of input voltages, often with a typical operating voltage of 24VDC14.
Specifications:
–Current: Capable of handling varying current requirements, with some specifications mentioning input currents up to 500mA and maximum output currents up to 15A4.
–Power Consumption: Low power consumption, with typical values less than 4W5.
Dimensions & Weight:
–Dimensions: Approximately 115mm x 48mm x 150mm (length x width x height), providing a compact form factor for easy installation4.
–Weight: Around 1.2kg to 2kg, depending on the specific variant or accessories included14.
–Input Quantity: 32 discrete inputs1.
–Input Voltage:
–AC: 230V AC (with specified voltage ranges for status 1 and 0)1.
–DC (as per another source): 19.2 VDC to 30.2 VDC2.
–Output Current: <=9.7mA at 47-53 Hz; <=11.5mA at 57-63 Hz1.
–Input Impedance: 31,800 Ohm at 47-53 Hz; 26,500 Ohm at 57-63 Hz1.
–Reaction Time: 7.3-12.3 ms (open-close); 4.9-0.75 ms x line cycle (close-open)1.
Dimensions and Weight:
Parameters:
–Voltage: Typically operates at 24V DC, with some sources mentioning voltage ranges or alternative voltages1.
–Current: Capable of handling currents up to 100-400A, depending on configuration and application1.
Specifications:
–Series: Belongs to Schneider Electric’s Modicon series of PLC modules21.
–Model: TSXASY410, a specific model within the Modicon line.
Dimensions & Weight:
–Dimensions: Approximate dimensions mentioned include 26x33x37mm2, but specific dimensions may vary based on mounting hardware or additional accessories.
–Weight: Typically around 2KG, making it suitable for panel mounting and industrial environments21.
–Output Type: Discrete DC Output
–Output Channels: 16 points
–Output Voltage: 24VDC (19V to 30V)
–Output Current: 0.5A per channel, with a maximum current of 10A per module
–Logic: Positive logic
–Compliance: Meets EN/IEC 61131-2 Type 3 DC Input/Output standards
Dimensions and Weight:
–Dimensions: Approximate dimensions may vary, but typical modules are designed for rack mounting. Specific dimensions are not provided but similar modules are typically compact for efficient space utilization.
–Weight: Approximately 0.12 kg, making it lightweight for easy handling and installation.
–Model Number: BMXP342020
–Manufacturer: Schneider Electric
–Series: Modicon M340
–Memory Capacity: 4096 KB total internal user memory (3584 Kb for programs, constants, and symbols + 256 Kb for data)12
–Input/Output (I/O) Capability: Supports up to 1024 I/O points across 4 racks23
–Processing Power: High processing speed, capable of executing up to 7K instructions per millisecond4
Dimensions and Weight:
–Weight: Approximately 0.205 kilograms2
–Dimensions: Exact dimensions are not provided, but it is designed for compact installation in low-depth cabinets (<150mm)1
Series:
Belongs to the Modicon M340 series of PLCs, a line of programmable automation controllers (PACs) designed for industrial automation
Parameters and Specifications:
–Model Number: 140NOE77101
–Brand: Schneider Electric
–Ethernet Protocol: Supports 10/100 Mbps Ethernet communication1
–Firmware Requirement: For use in dual-redundant hot standby structures, Firmware version must be greater than 2.0 to avoid communication issues during failover1
Dimensions and Weight:
–Dimensions: 90mm x 80mm x 62mm (Width x Height x Depth)2
–Weight: Approximately 1.25kg2
Parameters and Specifications:
–Model Number: 140DAM59000
–Brand: Schneider Electric
–Input Number: 16 points (can be grouped as 2 groups of 8)1
–Output Number: 8 points (can be grouped as 2 groups of 4)1
–Input Voltage: 115VAC, with options for 24VDC and 125VDC1
–Output Voltage: 115VAC, with voltage limits specified1
–Maximum Load Current: ≤8A per module, ≤4A per point1
–Reaction Time: ≤0.5ms for output response1
–Communication Protocols: Modbus, Ethernet, OPC2
Dimensions and Weight:
–Approximate Dimensions: 137mm x 483mm x 145mm
–Weight: 0.45kg1, or 2.2kg
