Parameters and specifications
Storage space: Has 2MB of storage space.
I/O capacity: 16k bit discrete I/O and 16k word analog I/O.
Communication interface:
Ethernet ports 1-10/100.
The USB interface is a standard 2.0 interface.
One additional RS-232 interface.
Supported functions:
Ladder diagram, structured text, function block diagram and C language programming.
Automatically locate symbol variables, using any amount of user memory.
Parameters and specifications
Brand: GE (General Electric)
Product features: Modules
Import or not: No (but the origin is in the United States)
Working voltage: 230V
Output frequency: 560kHz
Product certification: Qualified
Series: 26506506 (may be part of product series or model)
Material code: TED134050WL
Description: It is a simplex servo I/O terminal board manufactured and designed by General Electric and is part of the Mark VI series used in GE Speedtronic control systems
Parameters and specifications
Input voltage: 85 to 264 VAC (47 to 63 Hz) and 100 to 150 VDC
Maximum input power: Typical 440 watts, maximum 500 watts
Output: +5 VDC, +12 VDC, and -12 VDC power supplies are available, with a maximum output of 350 watts for all three outputs
Output current: 0-60 amps, 0-12 amps and 0-4 amps respectively
Operating input voltage: AC 85 to 264 V, DC 100 to 150 V, AC input frequency 47 to 63 Hz
Rated voltage: 120/240 VAC and 125 VDC
Power factor: When used in AC input power supply, the power factor is 0.99
Operating frequency: 47 to 63 Hz
Operating temperature range: 0 to 60 degrees Celsius
Size and weight
Size: 100mm x 50mm x 20mm
Weight: 1.2kg
Parameters and specifications
Order number: IC200CPUE05
Dimensions: 126 x 128 x 69.1 mm (W x H x D)
Program storage: system flash, battery-operated memory
Power requirements: 220mA for 5V, 570mA for 3.3V
Floating point: Support
Boolean execution speed: 0.8ms /K (typical value)
Real-time clock accuracy: 100ppm (0.01%) or +/- 9 seconds/day
Built-in communication: RS-232, RS-485, Ethernet
Configurable memory: Maximum 64K bytes
Ethernet data rate: 10Mbps (half-duplex or full-duplex)
Ethernet port: RJ-45, UTP
Maximum length of each twisted pair: usually 100m (when using high-quality five types of wire, the maximum length can reach 150m).
The number of hubs allowed to connect to a channel: 4, up to 5 segments of transmission media.
Topology: Star or bus shaped, but usually a star topology is used.
Access control mode: CSMA/CD (Carrier Sense multiple access/collision detection).
Frame length: Variable, maximum 1518 bytes.
Maximum transmission distance: Although the maximum length of each twisted pair is 100m, the maximum transmission distance of the entire network can reach 500m (through multiple HUB connections).
Processor speed: 33MHz (some data mention 133MHz, may be a different model or upgraded version).
Storage capacity: 240K bytes.
Maximum memory: 64K bytes.
Communication port: 1 Ethernet port, 1 serial port.
Operating temperature: 0°C~60°C.
Main specifications: According to the rated current ln, there are 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A and other specifications; According to the number of poles, there are 1P (unipolar), 2P (two poles), 3P (three poles), 4P (four poles) and so on; According to the form of the circuit breaker instantaneous trip device, there are type B (3ln~6ln), type C (5ln~10ln), type D (10ln~20ln) and so on.
