Parameter Specifications
Power Supply
Operates on a 24V DC power supply with a tolerance of ±10%. This stable power input ensures reliable performance in industrial settings where power fluctuations may occur.
Input Channels
It is equipped with multiple input channels. Specifically, it has 12 analog input channels. These channels are designed to accept signals from various types of sensors, such as thermocouples or RTDs (Resistance Temperature Detectors), depending on the specific configuration.
Signal Range
For thermocouple inputs, it can support a wide range of thermocouple types (e.g., J, K, T, E, etc.) with appropriate signal conditioning. When using RTDs, it can handle different resistance values corresponding to industry – standard RTD types.
Resolution and Accuracy
Offers high – resolution data acquisition. The analog – to – digital conversion typically has a high bit – resolution, ensuring accurate measurement of input signals. The measurement accuracy is also quite high, minimizing errors in temperature or other parameter measurements.
Uses
Temperature Monitoring
Its primary use is to monitor temperature in industrial processes. By connecting thermocouples or RTDs to the input channels, it can accurately measure the temperature at different points in a system, such as in a manufacturing process, a chemical reactor, or a power generation facility.
Process Control
The acquired temperature data can be used for process control. Based on the measured temperatures, the system can adjust other parameters, such as the flow rate of a coolant or the power input to a heater, to maintain optimal process conditions.
Data Logging
It can log the temperature data over time. This data can be used for quality control, troubleshooting, and predictive maintenance. Analyzing the historical temperature data can help identify trends and potential issues in the industrial process.
Weight and Dimensions
Weight
Approximately 0.6 kg, which is relatively light and easy to handle during installation and maintenance.
Dimensions
It has a compact design, with a length of about 140 mm, a width of 100 mm, and a height of 80 mm. This compact size allows it to be installed in standard control cabinets or other limited – space industrial environments.
Characteristics
Reliability
Built with high – quality components, it is designed to operate in harsh industrial environments. It is resistant to temperature variations, humidity, and electromagnetic interference, ensuring long – term and stable performance.
Flexibility
The ability to support multiple types of thermocouples and RTDs provides flexibility in different application scenarios. Users can choose the appropriate sensor type based on their specific temperature measurement requirements.
Ease of Installation and Configuration
It comes with user – friendly installation and configuration procedures. The input channels can be easily configured to match the connected sensors, and the module can be quickly integrated into existing industrial control systems.
Application Areas
Industrial Manufacturing
Used in metalworking, plastics processing, and food processing industries to monitor and control the temperature of manufacturing equipment, ensuring product quality and process efficiency.
Power Generation
Applied in power plants to monitor the temperature of turbines, generators, and other critical components, helping to prevent overheating and ensure safe operation.
Chemical and Pharmaceutical Industries
In chemical reactors and pharmaceutical manufacturing processes, it is used to monitor and control the temperature to ensure the accuracy and safety of chemical reactions and product quality.
