Specifications
Type : Integrated gate commutated thyristor (IGCT) module
series : ABB SHX series
application : high-performance switching and control of AC power supply
parameter
Rated voltage : 3300V AC
Rated current : 2600A
Peak forward current : 4000A
conducting voltage drop : 2.5V
gate trigger current : 0.5A
Operating temperature : -40°C to +85°C
Dimensions and weight
Dimensions : 385 mm x 250 mm x 120 mm
weight : 22kg (otherwise 2KG, need to be confirmed according to the specific product)
function
Control the flow of AC current in high-power applications to achieve controlled switching of high-voltage AC current.
Ideal for applications that require fast switching speeds, high efficiency and precise control
Main features
High performance : provides fast switching speed, high efficiency and precise control.
reliability : Rugged design ensures long term operation in harsh industrial environments.
compact design : Space saving and suitable for installation in narrow control cabinets.
Protection level : IP65 to protect against dust, water and other contaminants.
5SHX2645L0002 is widely used in industrial automation, power conversion, AC drives, renewable energy systems, power grid infrastructure, industrial power supplies and electric vehicles
